UHF 4W Longe Range DMR Digital Two Way Radio

DMR 1.8 LCD display 1800mAh SMS Tier Ⅰ&Ⅱ MOTOTRBO digital radio
  • Brand:

    HYDX
  • Item NO.:

    D60
  • Order(MOQ):

    500
  • Goods Stock:

    1
  • Payment:

    T/T,L/C,Credit Card,PayPal,Western Union,Cas
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Xiamen/Shenzhen
  • Lead Time:

    45~60
  • Weight:

    260

UHF 4W Longe Range DMR Digital Two Way Radio


Product Description:

·1.8 inch high definition LCD colorful display,  4/1W Output Power.

·Analog & Digital DMR Tier I & II standard, compatible with MOTOTRBO digital radio and other DMR radios,supports SMS,digital voice encryption,private/group/all call functions etc.

·High capacity battery 1800mAh,battery indicator,power save, able to meet daily operation needs. Equipped with a single base for charging, convenient and fast.

·Programming cable for easier computer/PC (Microsoft Window 7/8/10 only, No Mac supported) programming, free driver/firmware/programming software available on our website or download at our link, mess of video tutorials on YouTube.


Main Functions

1.400-470MHz

2.High/Low Power Switchable 4W/1W

3.High Battery Capacity 1800mAh

4.Monitor

5.Tail Elimination

6.Lone Worker

7.Message

8.Repeater

9.Talk Around

10.Normal/High SQL

11.Battery Indicator

12.Encryption

13.Power Save

14.Channel Scanning/Priority Scanning


Technical Specification

GENERAL
    Frequency Range

    VHF:400-470MHz

    RF Output Power     H:≤4W   L:≤1W
    Channels     16 Channels / 250 Zone
    Channel Spacing     12.5KHz
    CTCSS/DCS     50 CTCSS / 105 DCS
    Antenna Impedence     50Ω
    Operating Temperature     -30℃+60℃
    Operating Voltage     DC 7.4V
    Battery Type     2200mAh
    Dimension(Excluding antenna)     132(H)×62(W)×38(D)mm
    Weight(Battery,Antenna Including)     About 260g
TRANSMITTER
    Output Power

    H:≤4W

    L:≤1W

    Frequency Stability     +/-1.5ppm
    4FSK Modulation

    12.5KHz(date only):7K60FXD

    12.5KHz(date+voice):7K60FXE

    Free Time Slot Power

    ≤ -57 dBm

    Modulation Distortion     ≤ 3%
    Digital Audio Encode & Decode     AMBE+2TM
RECEIVER
    Analog Sensitivity

    0.35uV/-116dBm(20dB SINAD)

    0.22uV/-120dBm(Typical)

    Digital Selectivity

    0.3uV/-117.4dBm(BER5%)

    0.7uV/-110dBm(BER1%)

    Adjacent Channel Selectivity

    TIA603C:60dB@12.5KHz

    ETSI:60dB@12.5KHz

    Inter-modulation     TIA603C:65dB

    ETSI:65dB

    Block

    ≤ -84 dB

    Spurious Response Anti-Interference

    TIA603C:70dB

    ETSI:70dB

    Rated Output Power     1000mW
    Rated Audio Distortion     ≤ 3%

Packing&Delivery


Two-way Radio Walkie Talkie Gift Box, 10 pcs / carton.


*  1 x HYDX D60


*  1 x Antenna


*  1 x Battery


*  1 x Charger


*  1 x Belt Clip


*  1 x Hand Strap


*  1 x User Manual


*  1 x Adapter
