Brand:
HYDXItem NO.:
A910Order(MOQ):
500Payment:
T/T,PayPalProduct Origin:
ChinaColor:
BlackShipping Port:
Xiamen/ShenzhenLead Time:
40~50Weight:
260IP68 5W Dual Band Radio Noise Reduction Long Range Walkie Talkie
Product Description:
·AM aviation receiving; receive aircraft and tower calls; meet the individual needs of ham radio lovers.
·Two way radio receives AM / dual band frequencies; communication is more convenient and easier.
·IP68 waterproof rating; HYDX-A910 two-way radios are built to withstand even heavy rain or all kinds of bad weather; ensuring durability and longevity.
·Rechargeable two way radio; contains a rechargeable 2000mAh/3000mAh(optional) Li-ion battery; which can be used for a longer standby and usage time.
·Clear call quality; squelch function offers a clear sound quality; ensure smooth communication in a noisy environment.
·VFO for A910 handheld radio; manually edit the needed frequency or CTCSS/DCS through keyboard; as well as save them as regular channels.
·Quick Teaming; A910 ham radio supports pairing frequency of multiple same model walkie talkies, to bring convenience to group travel for multiple people.
·Digital Anti Cracking;Can achieve anti cracking function to avoid receiving illegal signals.
·USB C charging (optional); supports charging base and charging interface; makes it convenient to charge walkie talkie.
·Intelligent noise reduction (optional) for clear sound; the advanced two-way noise cancelling technology eliminates background noise for crystal audio quality even in the environment of noisy wind and roaring engine outdoors.
·Recording function allows you to record important matters at any time.
Main Functions
1.136-174MHz&400-470MHz
2.Stored 250*2 Channels Capacity
3.AM/FM
4.Air Band Received
5.Detection Frequency
6.Clone Mode
7.Digital Anti Cracking
8.Battery Save
9.Quick Teaming
10.VOX
11.Compandor
12.Scrambler
13.CTCSS/DCS
14.Scanning
15.Emergency Alarm
16.Recording
17.Noise Reduction (optional)
Technical Specification
GENERAL |
|
Frequency Range |
UHF:400-470MHz VHF:136-174MHz |
Channels | 250*2 |
Channel Spacing | Wide:25kHz Narrow:12.5kHz |
Operating Voltage | DC 7.4V |
Battery Type | Li-polymer |
Battery Capacity | 2000mAh/3000mAh (optional) |
Output Current | 450mA |
Charging Time | 4-6 hours |
Battery Life@5/5/90 |
Analog:15H |
Operating Temperature | -20℃+50℃ |
Audio Power Output | ≤2W@16Ω |
Dimension | 110.2(H)×56(W)×38.3(D)mm |
Weight | About 260g |
TRANSMITTER |
|
Carrier Output Power |
H:≤4W@UHF H:≤5W@VHF L:≤1W |
Carrier Frequency Tolerance | ≤±300Hz@200~500Hz |
Adjacent Channel Power |
≥60dB@12.5kHz ≥65dB@25kHz |
FM Noise |
11K0F3E@Analog (FM) |
Audio Distortion | ≤5% |
RECEIVER | |
Static Sensitivity | ≤ -124 dBm@12dB SINAD |
Co-Channel Inhibition | ≥-12dB |
Adjacent Channel Selectivity |
>60dB@12.5kHz >65dB@25kHz |
Inter-modulation Response Rejection | ≤ -55 dB |
Blocking | ≥84dB |
Receiver Spurious Emission |
<-57dBm@[<1GHz] <-47dBm@[>1GHz] |
Packing&Delivery
Two-way Radio Walkie Talkie Gift Box, 10 pcs / carton.
* 1 x HYDX A910
* 1 x Antenna
* 1 x Battery
* 1 x Charger
* 1 x Belt Clip
* 1 x Hand Strap
* 1 x User Manual
* 1 x Adapter
