UHF 5W Handheld Commercial Ham Radio

UHF 5watt 1600mAh long range rechargeable handheld two way radio
  • Brand:

    HYDX
  • Item NO.:

    A31
  • Order(MOQ):

    200
  • Payment:

    T/T,L/C,Credit Card,PayPal,Western Union,Cas
  • Product Origin:

    China
  • Color:

    Black/Red
  • Shipping Port:

    Xiamen/Shenzhen
  • Lead Time:

    45~60
  • Weight:

    230

UHF 5W Handheld Commercial Ham Radio


Product Description:

·Long Range Walkie Talkies.Left Side PTT allows you to make "direct calls" to the same channel members. GROUP PTT allows you to talk to other people simultaneously even they are not on the same channel. Ideal for on-site business applications, help work crews connect, coordinate and collaborate to get the job done right.

·Portable 2 Way Radios.Rotate the channel knob easy to switch the channel, adjustable volume level keeps sounds clarity without noise and distortion. The speakers on these handsets are crisp and loud, making it easy to hear an incoming signal even when used in noisy industrial environments. The display can easily read the status of the channel and setting. Anti-drop two-way radio can withstand harsh environments.

·Rechargeable Walkie Talkies.Worry-free Day Night Shift with a large-capacity 1600mAh lithium rechargeable battery. Working Time: 8-12 hours, Standby Time: 36-48 hours. Less than 4-5h to be fully charged quickly. Communicate effortlessly in working areas like hotel, school security,market,construction area and concert.


Main Functions

1.400-520MHz/245MHz/136-174MHz

2.Power Password Setting

3.Side-Key Programming

4.DTMF Encode/Decode

5.Key Lock Function

6.Reverse Frequency/Offset

7.BCLO

8.Scan/Priority Scan

9.Emergency Alert

10.PTT ID/ANI

11.Tail Elimination

12.VOX/IVOX

13.TOT

14.CTCSS/DCS


Technical Specification

GENERAL
    Frequency Range

    UHF:400-520MHz/245MHz

    VHF:136-174MHz

    RF Output Power     H:≤5W   L:≤2W
    Channels     199
    Channel Spacing     Wide:25KHz   Narrow:12.5KHz
    CTCSS/DCS     50 CTCSS / 105 DCS
    Antenna Impedence     50Ω
    Operating Temperature     -20℃+50℃
    Operating Voltage     DC 7.4V
    Battery Type     1600mAh
    Dimension(Excluding antenna)     110.5(H)×58.5(W)×35.6(D)mm
    Weight(Battery,Antenna Including)     About 230g
TRANSMITTER
    Output Power

    H:≤5W

    L:≤2W

    Modulation Mode     F3E
    FM Noise

    ≤ -45 dB

    Audio Distortion     ≤ 5%
    Spurious and Harmonics     -65 dB
RECEIVER
    Reference Sensitivity     ≤ -123 dBm@25K
    Adjacent Channel Selectivity     ≤ -65 dB
    Inter-modulation response immunity     ≤ -55 dB
    S/N

    ≥ 45 dB

    Rated Output Power     ≤750mW
    Rated Audio Distortion     ≤5%
Packing&Delivery


Two-way Radio Walkie Talkie Gift Box, 10 pcs / carton.


*  1 x HYDX A31


*  1 x Antenna


*  1 x Battery


*  1 x Charger


*  1 x Belt Clip


*  1 x Hand Strap


*  1 x User Manual


*  1 x Adapter
