2075W Noise Reduction Portable Amateur Two-Way Radio
Product Description:
·NOAA Weather Channels; Get 24/7 access to NOAA weather channels so you can always be prepared and connected with those you are traveling with in the instance you run into bad weather conditions.
·Rechargeable two way radio; contains a rechargeable 1600mAh Li-polymer battery; which can be used for a longer standby and usage time.
·Clear call quality; squelch function offers a clear sound quality; ensure smooth communication in a noisy environment.
·VFO for H510 handheld radio; manually edit the needed frequency or CTCSS/DCS through keyboard; as well as save them as regular channels.
·Quick Teaming; H510 ham radio supports pairing frequency of multiple same model walkie talkies, to bring convenience to group travel for multiple people.
·Private/Group/All Call; Enable digital services and select contacts for convenient communication. Current business can be distinguished by different groups.
·Digital Anti Cracking; Can achieve anti cracking function to avoid receiving illegal signals.
·Intelligent noise reduction (optional) for clear sound; the advanced two-way noise cancelling technology eliminates background noise for crystal audio quality even in the environment of noisy wind and roaring engine outdoors.
Main Functions
1.400-470MHz
2.Stored 250 Channels Capacity
3.NOAA (North America)
4.Private/Group/All Call
5.Detection Frequency
6.Clone Mode
7.Digital Anti Cracking
8.Battery Save
9.Quick Teaming
10.VOX
11.Compandor
12.Scrambler
13.CTCSS/DCS
14.Scanning
15.Emergency Alarm
16.FM
17.Frequency Hopping
18.Noise Reduction (optional)
Technical Specification
GENERAL |
|
Frequency Range |
UHF:400-470MHz |
Channels | 250 |
Channel Spacing | Wide:25kHz Narrow:12.5kHz |
Operating Voltage | DC 7.4V |
Battery Type | Li-polymer |
Battery Capacity | 1600mAh |
Output Current | 400mA |
Charging Time | 4-5 hours |
Battery Life@5/5/90 |
Analog:10H |
Operating Temperature | -20℃+50℃ |
Audio Power Output | ≤2W@16Ω |
Dimension | 113(H)×58(W)×38(D)mm |
Weight | About 207g |
TRANSMITTER |
|
Carrier Output Power |
H:≤4.6W L:≤1.2W |
Carrier Frequency Tolerance | ≤±1PPM@200~500Hz |
Adjacent Channel Power |
≤-60dB@12.5kHz ≤-65dB@25kHz |
Modulation Mode |
11K0F3E@Analog (FM) |
Transmit Spurious Emission | ≥30dB |
Audio Response | +1/-3B |
Audio Distortion | ≤5% |
RECEIVER | |
Static Sensitivity | ≥-117 dBm (Eer≤5%) |
Co-Channel Inhibition | ≥-12dB |
Adjacent Channel Selectivity |
>60dB |
Spurious Response Immunity | ≥70dB |
Inter-modulation Response Immunity NTER | ≥60dB |
Blocking | ≥84dB |
Receiver Spurious Emission |
≥57dB |
Packing&Delivery
Two-way Radio Walkie Talkie Gift Box, 10 pcs / carton.
* 1 x HYDX H510
* 1 x Antenna
* 1 x Battery
* 1 x Charger
* 1 x Belt Clip
* 1 x Hand Strap
* 1 x User Manual
